ATC-PP10 Material Composition

ATC-PP10 made by injection-moulded Process, it is a reinforced Polyacetal with PTFE Fibres known for its good bearing properties, particularly in applications requiring low friction and high wear resistance. ATC-PP10 is a modified version of POM , incorporating features like PTFE and graphite to enhance performance.

ATC100
Performance IndexUnitsValue
Max Dynamic LoadMpa40
Max Static LoadMpa65
Working Temperature°C-30 - +120
Max Linear Velocitym/s1
Max Pv Valuesm/s x Mpa2.8
Coefficient of Friction0.08 - 0.18

Benefits of ATC-PP10

  • Reduced Friction and Wear:ATC-PP10 material has very less friction and wear on moving parts, leading to longer service life.
  • Self-Lubricating:Reduces or eliminates the need for external lubricants, lowering maintenance costs.
  • Corrosion Resistance:Suitable for use in corrosive environments due to their resistance to chemicals, moisture, and solvents.
  • Noise Reduction:Can dampen noise and vibration, contributing to quieter operation.
  • Lightweight:Generally lighter than metal alternatives, which can be beneficial in applications like aerospace and automotive.
